TP-Link TL-WDR4900 N900 WiFi Dual Band Gbit Router

TP-Link TL-WDR4900 N900 Wireless Dual Band Gigabit Router

OVERVIEW
TL-WDR4900 is a performance optimized simultaneous dual band wireless N router combining the blazing fast speeds of up to 450Mbps over the crystal clear 5GHz band and the traditional 2.4GHz band. With 900Mbps of total bandwidth, CPU Clock Speeds of up to 800MHz, 3 external antennas serving the 5GHz band, and 3 internal antennas serving the 2.4GHz band, you can run multiple bandwidth intensive applications in a large home or office. Simple tasks like sending e-mails or web browsing can be handled by the 2.4GHz band while bandwidth intensive tasks like online gaming or HD video streaming can be processed by the 5GHz band– all at the same time.

If you prefer a wired connection, the TL-WDR4900 boasts five gigabit ports and 900Mbps+ hardware NAT to provide a lightning-fast and lag-free experience. The two USB 2.0 ports will allow you to power a robust home Internet network by sharing printers, flash storage, ftp servers, or media players.

FEATURES
• Simultaneous 2.4GHz 450Mbps and 5GHz 450Mbps connections for 900Mbps of total available bandwidth
• Full gigabit ports ensure ultimate transfer speeds
• Achieves blazing WAN to LAN throughput of over 900Mbps with hardware NAT
• CPU Clock Speeds of up to 800MHz can handle more data much faster
• 3*5dBi external antennas and 3 internal antennas provide maximum wireless coverage and reliability
• Dual USB Ports - easily share printers, files or media with your friends or family locally or over the internet

HARDWARE FEATURES
Interface
• 4 10/100/1000Mbps LAN Ports
• 1 10/100/1000Mbps WAN Port
• 2 USB 2.0 Ports

Button
• WPS/Reset Button
• Wireless On/Off Switch
• Power On/Off Button

External Power Supply
• 12VDC / 2.5A

Dimensions ( W x D x H )
• 243x160.6x32.5mm

Antenna Type
• Three 5GHz 5dBi detachable antennas (RP-SMA)
• Three 2.4GHz internal antennas

WIRELESS FEATURES
Wireless Standards
• IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n

Frequency
• 2.4GHz and 5GHz

Signal Rate
• 5GHz: Up to 450Mbps
• 2.4GHz: Up to 450Mbps

EIRP
• <20dBm(EIRP)

Wireless Functions
• Enable/Disable Wireless Radio, WDS Bridge, WMM, Wireless Statistics

Wireless Security
• 64/128-bit WEP,WPA / WPA2,WPA-PSK/ WPA2-PSK encryption

SOFTWARE FEATURES
WAN Type
• Dynamic IP/Static IP/PPPoE/
• PPTP(Dual Access)/L2TP(Dual Access)/BigPond

DHCP
• Server, Client, DHCP Client List,
• Address Reservation

Quality of Service
• WMM, Bandwidth Control

Port Forwarding
• Virtual Server, Port Triggering, UPnP, DMZ

Dynamic DNS
• DynDns, Comexe, NO-IP

VPN Pass-Through
• PPTP, L2TP, IPSec

Access Control
• Parental Control, Local Management Control, Host List, Access
• Schedule, Rule Management

Firewall Security
• DoS, SPI Firewall
• IP Address Filter/MAC Address Filter/Domain Filter
• IP and MAC Address Binding

Protocols
• IPv4, IPv6

USB Sharing
• Support Samba(Storage)/FTP Server/Media Server/Printer Server

Management
• Access Control
• Local Management
• Remote Management

OTHERS
Certification
• CE, FCC, RoHS

System Requirements
• Microsoft Windows 98SE, NT, 2000, XP, Vista or Windows 7, Windows 8, MAC OS, NetWare, UNIX or Linux.

Environment
• Operating Temperature: 0°C~40°C (32°F ~104°F)
• Storage Temperature: -40°C~70°C (-40°F ~158°F)
• Operating Humidity: 10%~90% non-condensing
• Storage Humidity: 5%~90% non-condensing
